From the call to tender to the preliminary draft (1959-1962)
Preliminary Draft – Drainage
As early as 1961, a drainage system was presented in the Preliminary Draft, which was to be further developed in the execution plan [i].
Three subsystems were defined, using different techniques according to the characteristics of the area they drained:
– Drainage system in a “blind trench”, under the peripheral circulation.
– Piped drainage system under the areas to the east and south that correspond to the areas defined as the Park, and under part of the protected area to the northeast.
– Groundwater drainage system on the roof of the parking lot.
Tags
Details
- Main authors:
- BARRETO, António Facco Viana, TELLES, Gonçalo Pereira Ribeiro
- Secondary authors:
- FCG – Serviço de Projectos e Obras*
- Spatial Coverages:
- 1961
- Typology:
- Photography
- Phase:
- From the call to tender to the preliminary draft (1959-1962)
- Materials:
- drain, trench
- Identifiers:
- PT FCG FCG:SCT-S006-DES01107
In order to consult the original version of this document you should contact the Gulbenkian Archives by e-mail [email protected]
and refer the document´s ID
